Gateway
Jupiter 812
Ethernet and Wi‑Fi only gateway. No cellular, no GNSS. 1 RS485, 1 Ethernet. 4 MB, no backup battery. -40 °C to +85 °C.
Ethernet + Wi‑Fi
Wired and wireless LAN only.
RS485
Serial interface.
Compact
No cellular or GNSS.
Wide temp
-40 °C to +85 °C.
Tor Apollo
FOTA via Tor Apollo for provisioning and updates.
Take a closer look.
IEEE 802.11 wireless connectivity allows network integration without physical cabling, simplifying installation in environments with existing WiFi infrastructure.
BLE 4.2 enables wireless connection to fuel sensors and asset beacons, expanding monitoring capability without additional wiring.
Built-in Ethernet port enables high-speed wired network integration for fixed installations where cellular is unnecessary or unavailable.
At 170×110×42 mm with IP65 rating, fits tight installation spaces fully sealed against dust and water ingress.
Technical specifications.
power
- Supply voltage
- 12–30 V DC
- Backup battery
- NA
communication
- Ethernet
- 1
- Wi‑Fi
- Yes
- Cellular
- NA
- GNSS
- NA
- Memory
- 4 MB
interfaces
- RS485
- 1
- Ethernet
- 1
physical
- Dimensions
- Per Jupiter series
- Harness
- —
environmental
- IP
- IP65
- Operating temp
- -40 °C to +85 °C
Tor Apollo – Device Configuration & Provisioning
Configure and manage this gateway with Tor Apollo. Web-based setup, FOTA updates, and provisioning for deployment and maintenance without on-site visits.
Learn about Tor Apollo →Use cases
Practical applications for industrial and building connectivity with Jupiter 812.
LAN-only telemetry
RS485 and Ethernet where Wi‑Fi/cable available.
Building and facility
Wi‑Fi and Ethernet for indoor deployment.
Cost-sensitive deployment
No cellular or GNSS hardware.
Wiki knowledge base
Firmware, first-start guides, usage scenarios, and certificates.
